lignite coal briquetting machine:
Specifications
coal briquetting machine
1.application:all kinds of power
2.ISO and CE approved
3.high briquette ratio
4.strong structure
lignite coal briquetting machine ,which is not only used in coal ,but widely used in
metallurgical, chemical,and refractories industries, It is suitable for many materials such as light burning magnesium, iron oxide skin, manganese alloy, sludge, gypsum, carbon, silicon carbide, copper powder, iron powder and various refractory materials.
features of lignite coal briquetting machine:
Special designed mandatory feeder. The machine can press pure powder material with feature of light weight and small density like charcoal powder.Special designed assistant equipment. It has fully automatic feeding, sending system. Humanized design makes the machine’s cleaning and maintenance more easily. Special Installation structure makes the change and repair of parts convenient.
Working Principles of high briquette ratio lignite coal briquetting machine :
This series machine will pass the powder on to the two pressure roller through the reducer.The two sides and roll rotation, in both the rotating roll. Natural materials to enter the ball roll mode, with the roll rotation, material pressure on a small become larger, When the material to the two rollers rotating line contact point, the pressure of materials has reached the peak. Tremendous pressure in the role of line, the materials become a finished product from the powder ball.
parameters of lignite coal briquetting machine
|
Model |
Reducer |
Ratio |
Roller size |
Spindle speed(r/min) |
Motor model |
Power (kw) |
Yield (t/h) |
|
YHQ360-4 |
ZQ350 |
1:31.5 |
360*250 |
15-17 |
Y132M-4 |
7.5 |
3-5 |
|
YHQ400-4 |
ZQ400 |
1:31.5 |
400*250 |
15-17 |
Y160M-4 |
11 |
4-7 |
|
YHQ430-4 |
ZQ400 |
1:31.5 |
430*250 |
15-17 |
Y160M-4 |
11 |
5-8 |
|
YHQ500-2 |
ZQ500 |
1:31.5 |
500*350 |
15-17 |
Y160L-4 |
15-30 |
8-10 |
PLS NOTICE:
Yonghua Machinery has many type high briquette ratio coal briquette press machine ,if you have any kinds of raw material and want to make them into briquettes ,please contact me freely.we will provide you a competitive price and excellent machine ,sincerely waiting for your inquiry.
