High pressure Arab popular shicha hookah charcoal coal 25*25*25mm cubic briquettes making machine
Brief Introduction:
Shisha charcoal machine is specilize in make shisha hookah briquettes. This machine use hydraulic principle, owing to the pressure is very large, so it can press good quality final product, so does the briquette quality is very good, our machine use PLC system, and about the product line, we can achieve all automatic production, of course, if you are beginner, want lower invest, we also can offer you semi-automatic production line. Machine include PLC system, hydraulic cylinder, conveyor, molds and main machine.
Main parameters:
| Model | Mechanical | Hydraulic |
| Technical parameter | Type : mechanical shisha charcoal making machine | Name:Hydraulic pressure shisha charcoal making machine |
| Component: shisha machine |
Component: Shisha machine, PLC Electric control cabinet, Hydraulic pump |
|
| Motor power: 7.5kw | Motor Power(kw): 15kw; conveyor power (kw): 0.75kw; Feeding power(kw): 0.75kw | |
| Shape: cubic, tablet round, hexagon | Shape :Cube, tablet round, hexagon | |
| Final briquette size: according to customized | Final briquettes size: customized | |
|
Capacity: 10-15pieces/time 22times/min, about 600-800kg/h |
Capacity: Cube 44 pieces/time, 3-5 times/min Tablet round shape: 38 pieces, 3-5 pieces/min hexagon shape: 26pieces, 3-5pieces/min About 600-800kg/h |
|
| Pressure: 20-30t | Pressure: 100-120t | |
| Press type: piston | Press type: Hydraulic press | |
| 3500*1200*1750mm |
DimensionMachine:2.1m*1m*2m PLC Electric control cabinet: 900mm(L)*550(W)*1100(H) Hydraulic pump:1300*900*1200 Conveyor:1500mm |
Festures:
(1) NO binder needed during production to make clean & green fuel briquette.
(2) Quantity of heat of final product is 500-1000Kcal higher than raw material.
(3) Can replace firewood and liquefaction gas, with less investment.
(4) Small cubage and easy for transport.
(5) Adopt high-speed, high-frequency stamping technique, ensure the stability of the molding.
1.Size and shapes:
1) Size: round: 20-45mm, square: 15-55mm
2) Shape: round, square, restabgle, triangle, cylinder, diamound, cone, etc.
3) The shape of briquettes can be customized.
2. Characteristics:
1) The shisha charcoal briquettes use quick burning charcoal technology, can burn from the top to down.
2) Firepower fierce, smokeless, tasteless, non-toxic, long burning time.
3) Square shape shisha charcoal can burn for about 1-1.5 hours.
4) Round tablet shisha charcoal can burn for about 40 minutes.
Application:
The Shisha tablet press is widely used in refractory, power plants, metallurgy, chemicals, energy, transportation, heating, etc.
Shape and size
Related equipment:
If you want to learn more information, please contact us.
